Name: Elevation Contours 2019

Display Field: ELEVATION

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This data set is one component of a digital terrain model (DTM) for St. Johns County. The dataset is comprised of mass points, 2-D and 3-D breakline features, 1-foot and 2-foot contours, ground control, vertical test points, and a footprint of the data set, in the ESRI ArcGIS File Geodatabase format. In accordance with the counties specifications, the following breakline features are contained within the database: closed water bodies (lakes, reservoirs, etc) as 3-D polygons; linear hydrographic features (streams, shorelines, canals, swales, embankments, etc) as 3-D breaklines; coastal shorelines as 3-D linear features; edge of pavement road features as 3-D breaklines; soft features (ridges, valleys, etc.) as 3-D breaklines; island features as 3-D polygons; concretedam, culvert, footprint, lowconfidence, lowconfidenceanno, overpass, pipe, roadcenterlineoverbridge and swamppoint as 2-D features. Contours were generated from LiDAR ground class and breaklines and meet National Map Accuracy Standards. The LiDAR masspoints are delivered in the LAS file format based on the Florida statewide 5,000' by 5,000' grid. Breakline features were captured to develop a hydrologically correct DTM. The GEOID model used to reduce satellite derived elevations to orthometric height is GEOID12A. The coastalshoreline has a constant value of -0.6’ that was statistically derived from the LiDAR point cloud collected within the 2-hour window of MLL tide. 2008 Hydrographic and soft features were used to supplement the 2019 breaklines in Low Confidence areas.</SPAN></P></DIV></DIV></DIV>

Service Item Id: 4b1a4b2f5be049a9913248a977354abe

Copyright Text: Data content is created and/or maintained by the St. Johns County GIS Division and Woolpert, Inc.

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 24000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -9091402.6326
YMin: 3454036.5062000006
XMax: -9040517.2472
YMax: 3537125.5591999963
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: CONTOUR
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: 1
  Label: 1
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [168, 112, 0, 255]
  Width: 1
• Value: 5
  Label: 5
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [191, 168, 124, 255]
  Width: 0
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: [ELEVATION]
Use Coded Values: true
Symbol:
Color: [115, 38, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: center
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Arial
Font Style: normal
Font Weight: bold
Font Decoration: none

Min. Scale: 5000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• ELEVATION ( type: esriFieldTypeSmallInteger, alias: ELEVATION )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape_Length )
• CONTOUR ( type: esriFieldTypeSmallInteger, alias: CONTOUR )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
